Beach infrastructure

Technical drawings
Drawings detailing technical guidance for embellishment design
Table 1: Beach infrastructure - Technical drawing index
Embellishment | Description/drawing code | Product details/supplier | Other |
![]() | Fence (type 1) - post and plastic filament | Post: no supplier specified. Wire: Bayco sighter wire - plastic filament (or equivalent). | |
![]() | Fence (type 2) - post and rail | Post and rail: no supplier specified. | |
![]() | Fence (type 3) - post and rail with plastic filament | Post and rail: no supplier specified. Wire: Bayco sighter wire - plastic filament (or equivalent). | |
![]() | Fence (type 4) - post and rail with cloth and coated mesh | Post and rail: no supplier specified. Wire: Waratah Stocksafe-T longlife wire (or equivalent). Knitted shade cloth: no supplier specified. | Multiple cloth colour options available: black (preferred) or green. Cloth must be rated greater than 80% light reduction. |
![]() | Fence (type 5) - post and coated mesh | Post and rail: no supplier specified. Wire: Waratah Stocksafe-T longlife wire (or equivalent) | |
![]() | Beach access - timber and chain - pedestrian and vehicular | No supplier specified. |
Luminance contrast: Note product images depict samples of products only. Luminance contrast requirements refer to the product and the background against which it is installed.
This component is currently in development
